NAN YA NPSN-901X75 is a 75% non-volatile solution of poly(bisphenol a-co-epichlorohydrin) glycidyl end-capped in xylene, designed for use in anticorrosive paints. When cured with polyamide or polyamine hardeners, it provides good chemical resistance and strong physical properties. This liquid epoxy resin functions as a binder and resin, offering durability and performance in coatings.

Chemical Family: Epoxy & Epoxy Derivatives

End Uses: Anti-Corrosion Paint

Features: Chemical Resistance

Synonyms: 2,2-Bis(4-glycidyloxyphenyl)propane-2,2-bis(hydroxyphenyl)propane copolymer, 4,4′-Isopropylidenediphenol-Rutapox 0162 copolymer, Araldite GT 6750, Bisphenol A diglycidyl ether-bisphenol A copolymer, Bisphenol A diglycidyl ether-bisphenol A-dodecylphenol copolymer, Bisphenol A-bisphenol A diglycidyl ether copolymer, Bisphenol A-bisphenol A diglycidyl ether polymer, Bisphenol A-bisphenol A diglycidyl ether-piperidine copolymer, Di(4-hydroxyphenol)isopropylidene diglycidyl ether-di(4-hydroxyphenol)isopropylidene copolymer

Enhanced TDS

Identification & Functionality

Chemical Family
Chemical Name
Manufactured By
CASE Ingredients Functions
Technologies
Product Families
Product Composition

Diglycidyl ether of Bisphenol-A ( 75% ) + Xylene ( 25% )

Features & Benefits

CASE Ingredients Features

Applications & Uses

Coating End Applications
Application Information

Anticorrosive paint.

Properties

Physical Form
SDS Physical and Chemical Properties
ValueUnitsTest Method / Conditions
Soluble InWater--
Relative Density (at 20°C)1.09g/cc-
Explosion Limits1.0 - 7.0%-
Flash Point49°CClosed cup
Boiling Point (Xylene)137 - 140°C-
OdorAromatic--
AppearanceYellowish Liquid--
Specifications
ValueUnitsTest Method / Conditions
N.V74 - 76%-
Viscosity (at 25°C)8000 - 15000cPs-
Colormax. 1.0-Gardner
Epoxy Equivalent Weight450 - 500g/eq-
Physical StateLiquid--

Technical Details & Test Data

Viscosity vs Temperature Characteristics

NAN YA NPEL-128 - Viscosity VS. Temperature Characteristics - 1

Storage & Handling

Shelf Life
min. 12 months
Storage Information

At least 12 months in sealed containers at ambient temperature. The resin should be stored in a dry place in its original closed packaging.

Handling Advice

Product may cause skin and eye irritation. In cases of skin contact wash immediately with soap and water. For eyes, flush with plenty of water for 15 minutes and seek medical attention immediately.
